Array Pattern Segment Reinforced Concrete Saw Blade Handheld 12 Inch 14in 16inch

Basic Information
Place of Origin: Wuhan
Brand Name: WANBANG
Certification: ISO9001
Model Number: 300-400mm
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: carton case
Delivery Time: 10-14 days delivery time
Payment Terms: T/T
Type: Dry And Wet Cutting Diamond Circular Saw Blade Color: Customized
Application: Reinforced Concrete, Old Concrete, Cured Concrete, Concrete Slab, Precast Slab Hard Brick, Masonry Product Name: Diamond Saw Blade
Advantage: 3 Times Durable Life Machine: Table Saw, Walk-behind Saw, Handhelded Saw, Wall Saw
Process: Laser Welded Material: High Quality Diamond
Teeth: 21T/24T/28T Diameter: 12" 14" 16"
High Light:

Segment Reinforced Concrete Saw Blade


Array Pattern Reinforced Concrete Saw Blade


14in Handheld General Purpose Saw Blades

Array Pattern Segment 12 Inch/14inch/16inch Reinforced Concrete Saw Blade For Handheld Saw



Application: Reinforced concrete, old concrete, cured concrete, concrete slab, precast slab hard brick, masonry, general construction materials.
* Segments with even distribution diamond grits which precisely layout in three dimensional patterns can produce best performance with faster and consistent cutting and longer lifetime
* Dry or wet cutting
* Applicable for table saw, walk-behind saw, handhelded saw, wall saw
* Different quality grade: Economic, standard, premium, professional
* 1" arbor with drive pin holes standard. Custom arbor sizes are available.
* Other special specifications and colors can be produced by clients' require


Diameter Seg. LxT(mm) Seg. height Seg.No. Cutting Materials
12" 300mm 40*3.0 12/15mm 21 Concrete/General purpose
14" 350mm 40*3.2 12/15mm 24 Concrete/General purpose
16" 400mm 40*3.4 12/15mm 28 Concrete/General purpose
18" 450mm 40*3.6 12/15mm 32 Concrete/General purpose
20" 500mm 40*3.6 12/15mm 36 Concrete/General purpose
24" 600mm 40*3.6 12/15mm 42 Concrete/General purpose
26" 650mm 40*4.0 12/15mm 42 Concrete/General purpose
28" 700mm 40*4.0 12/15mm 45 Concrete/General purpose
32" 800mm 40*4.0 12/15mm 52 Concrete/General purpose
36" 900mm 40*4.5 12/15mm 56 Concrete/General purpose


Array Pattern Segment Reinforced Concrete Saw Blade Handheld 12 Inch 14in 16inch 0Array Pattern Segment Reinforced Concrete Saw Blade Handheld 12 Inch 14in 16inch 1

WUHAN WANBANG LASER DIAMOND TOOLS CO., a dynamic company, driven by a team of experienced Doctor and Master specialized in powder metallurgy and laser welding technology, was established in 1999. We are specialized in producing and developing all kinds of diamond tools, which have wide range of applications in architecture, stone process, decoration and highway project, etc.


As a ISO9001: 2000 certified company, Wan bang has very strict quality control system, all products exported to the U. S. A., Germany, UK and many other countries, and enjoy very good reputations in the mainstream market.


Our products including: Laser welded diamond concrete saw blades, asphalt saw cutting blade, granite cutting disc, refractory brick diamond blade, diamond core drill bits for reinforced concrete, diamond grinding cup wheel and diamond grinding shoes, diamond wall saw blade, floor saw blade, ring saw for handheld machine, wire saw for demolition, tuck point blade for grooving.


Array Pattern Segment Reinforced Concrete Saw Blade Handheld 12 Inch 14in 16inch 2
